Mic Preamp:
- Gain: 0 to 66 dB in 6 dB steps.
- Phantom Power: +48V for condenser microphones.
- Polarity Inversion: Inverts the polarity of the signal.
- High Pass Filter: 80 Hz, 12 dB/Octave Bessel slope.
- Microphone Input Impedance: 10,000 Ohms.
DI Input:
- Gain: 0 to 30 dB, continuously variable.
- Instrument Input Impedance: 1.6 Meg Ohms (3.3 Meg Ohms balanced).
- Thru & Inst 1/4″ Phone Jacks: For instrument direct input and thru output.
- Blend Control: Allows blending of the DI and mic preamp signals.
Compressor:
- Opto-coupler compressor with a single threshold control.
- Compression Ratio: Fixed at 2:1.
- Attack & Release Times: Fixed, with a Fast Mode (Attack 40ms, Release 40ms) and Slow Mode (Attack 100ms, Release 350ms).
- LED indicators for signal presence, clipping, and compression status.
Sound Shaping Features:
- Silk Circuit: Enhances harmonic content, reminiscent of vintage class-A designs.
- Vari-Phase Control: Allows for phase alignment of two signals with the same source.
Frequency Response:
- Mic Pre, Main Output, no load: -0.1 dB @ 10 Hz, -1 dB @ 120 kHz.
- DI Input, Main Output, no load: -0.1 dB @ 10 Hz, -1 dB @ 120 kHz.
Noise:
- Measured at Main Output, unweighted, 22Hz 22kHz, Terminated 150 Ohms.
- With gain at unity: Better than -100 dBu.
- With gain at 66 dB: Better than -60.5 dBu.
- Equivalent Input Noise: Better than -125 dBu.
Maximum Output Level:
- Maximum output from 20 Hz to 40 kHz is +23 dBu.
Total Harmonic Distortion and Noise:
- @ 1 kHz, +20 dBu output: Main Output: Better than 0.001%.
- @ 20 Hz, +20 dBu output: Main Output: Better than 0.002%.
- Silk Engaged: Better than 0.2% Second harmonic.
Vari-Phase:
- Phase control at different frequencies.
- @ 100 Hz: 2.9 degrees to 57.4 degrees.
- @ 1 kHz: 33.5 degrees to 156 degrees.
- @ 10 kHz: 149 degrees to -175 degrees.
Phantom Power:
- +48 Volts DC +/1% (provided by 500 Series Rack).
Power Requirements:
- Supplied by 500 series rack with 110-125 mA @ +/16V.
Crosstalk:
- Measured channel to channel: Better than -90dB at 15kHz.
